OE 3QF615301F products
AUDI (SAIC): 3QF615301F
VAG: 3QF 615 301 F
VAG: 3QF615301F
VW: 3QF 615 301 F
VW: 3QF615301F
VW (SVW): 3QF615301F
OE number or original number means the number of the whole component or part of it installed on the vehicle on the production line by the car manufacturer. The meaning of the OE number is equivalent to "Genuine Number"
| Fitting Position | Front Axle |
| Brake Disc Type | vented |
| Processing | High-carbon |
| Surface | Coated |
| Outer Diameter | 335mm |
| Brake Disc Thickness | 30mm |
| Height | 50mm |
| Rim | 5-Hole |
| Bolt Hole Circle Ø | 112mm |
| Centering Diameter | 65mm |
| Appr. stamp | ECE R90 APPROVED |
| Min. thickness | 27mm |
| Hole Pitch/Number | 10/5 |
| Weight | 11.6kg |
| More information » | |
$69.90
$82.30
-16%
Sold in pairs
| Brake Disc Type | Vented |
| Outer Diameter | 335mm |
| Brake Disc Thickness | 30mm |
| Min. thickness | 27mm |
| Num. of holes | 9 |
| Thread Size | 15, 3 |
| Bolt Hole Circle Ø | 112mm |
| Height | 49.6mm |
| Centering Diameter | 65mm |
| Colour | black |
| Surface | painted |
| Appr. stamp | E1 90R-02 C0176/0636 |
| SVHC | No information available, please contact the manufacturer! |
| More information » | |
| Brake Disc Type | Vented |
| Num. of holes | 5 |
| Appr. stamp | R90 Homologated |
| Surface | Coated |
| Processing | High-carbon |
| Outer Diameter | 335mm |
| Brake Disc Thickness | 30mm |
| Min. thickness | 27mm |
| Bolt Hole Circle Ø | 112mm |
| Centering Diameter | 65mm |
| Height | 49.5mm |
| More information » | |
| Fitting Position | Front Axle |
| Brake Disc Type | vented, Perforated |
| Processing | High-carbon |
| Surface | Coated |
| Outer Diameter | 335mm |
| Brake Disc Thickness | 30mm |
| Height | 50mm |
| Rim | 5-Hole |
| Bolt Hole Circle Ø | 112mm |
| Centering Diameter | 65mm |
| Appr. stamp | ECE R90 APPROVED |
| Min. thickness | 27mm |
| Hole Pitch/Number | 10/5 |
| Weight | 11.5kg |
| More information » | |
$93.90
$110.50
-16%
Sold in pairs
| Brake Disc Type | vented |
| Outer Diameter | 335mm |
| Brake Disc Thickness | 30mm |
| Height | 49.6mm |
| Min. thickness | 27mm |
| Processing | High-carbon |
| Surface | Coated |
| Inner Diameter | 145mm |
| Bolt Hole Circle Ø | 112mm |
| Centering Diameter | 65mm |
| Hole Pitch/Number | 05/10 |
| Wheel Bolt Bore Ø | 15.3mm |
| Supplementary Article/Supplementary Info 2 | without wheel hub, without wheel bearing, without wheel studs |
| Packaging length | 34.3cm |
| Packaging width | 34.3cm |
| Packaging height | 7.5cm |
| Weight | 11.6kg |
| More information » | |
