OE 424973 products
ALFA ROMEO: 4249.73
ALFA ROMEO: 424973
CITROËN: 424973
CITROËN: 4249.73
CITROËN: 4249 73
CITROËN/PEUGEOT: 4249.73
CITROËN/PEUGEOT: 424973
CITROËN/PEUGEOT: 4249 73
FIAT: 424973
FIAT: 4249.73
LANCIA: 424973
OPEL: 4249.73
PEUGEOT: 4249.73
PEUGEOT: 4249 73
PEUGEOT: 424973
PEUGEOT: 4249-73
PEUGEOT (DF-PSA): 424973
VW: 4249.73
OE number or original number means the number of the whole component or part of it installed on the vehicle on the production line by the car manufacturer. The meaning of the OE number is equivalent to "Genuine Number"
| Fitting Position | Front Axle |
| Brake Disc Type | Vented |
| Brake Disc Thickness | 22mm |
| Outer Diameter | 257mm |
| Surface | Oiled |
| Height | 40.4mm |
| Min. thickness | 20.2mm |
| Centering Diameter | 59mm |
| Num. of holes | 4 |
| Bolt Hole Circle Ø | 98mm |
| Thread Size | 13 |
| More information » | |
$14.50
$17.00
-15%
Sold in pairs
| Fitting Position | Front Axle |
| Brake Disc Type | Vented |
| Brake Disc Thickness | 22mm |
| Outer Diameter | 257mm |
| Surface | Coated |
| Height | 40.4mm |
| Min. thickness | 20.2mm |
| Centering Diameter | 59mm |
| Num. of holes | 4 |
| Bolt Hole Circle Ø | 98mm |
| Thread Size | 13 |
| More information » | |
$15.70
$18.40
-15%
Sold in pairs
| Outer Diameter | 257mm |
| Brake Disc Thickness | 22mm |
| Height | 41mm |
| Centering Diameter | 59mm |
| Num. of holes | 4 |
| Bolt Hole Circle Ø | 13mm |
| Min. thickness | 20.2mm |
| Brake Disc Type | Vented |
| Inner Diameter | 127mm |
| Surface | Coated |
| Fitting Position | Front Axle |
| Supplementary Article/Supplementary Info 2 | without bolts/screws |
| More information » | |
| Fitting Position | Front Axle |
| Brake Disc Type | Vented |
| Outer Diameter | 257mm |
| Brake Disc Thickness | 22mm |
| Height | 40.3mm |
| Min. thickness | 20.2mm |
| Centering Diameter | 59mm |
| Bolt Hole Circle Ø | 98mm |
| Surface | Oiled |
| More information » | |
| Fitting Position | Front Axle |
| Brake Disc Type | Vented |
| Outer Diameter | 257mm |
| Brake Disc Thickness | 22mm |
| Height | 40.4mm |
| Bolt Hole Circle Ø | 98mm |
| Centering Diameter | 59mm |
| Num. of holes | 4 |
| Min. thickness | 20.2mm |
| More information » | |
| Brake Disc Type | Vented |
| Outer Diameter | 258mm |
| Brake Disc Thickness | 22mm |
| Quantity required | 2 |
| Replace in pairs only | |
| Height | 40.5mm |
| Bolt Hole Circle Ø | 98mm |
| Centering Diameter | 59mm |
| Num. of holes | 4 |
| Appr. stamp | ECE R90 |
| Assy./disassy. by qualified personnel required! | |
| More information » | |
| Rim | 4-Hole |
| Height | 41mm |
| Brake Disc Type | Vented |
| Brake Disc Thickness | 22mm |
| Min. thickness | 20.2mm |
| Outer Diameter | 257mm |
| Centering Diameter | 59mm |
| Bolt Hole Circle Ø | 98mm |
| More information » | |
| Brake Disc Type | Vented |
| Outer Diameter | 258mm |
| Brake Disc Thickness | 22mm |
| Min. thickness | 20.2mm |
| Inner Diameter | 127mm |
| Bore Ø | 13mm |
| Bolt Hole Circle Ø | 98mm |
| Num. of holes | 4 |
| Height | 40.5mm |
| Centering Diameter | 59mm |
| EU General Product Safety Regulation (GPSR) | IEC 60417-6183 mechanical expertise required |
| More information » | |
$18.60
$21.90
-16%
Sold in pairs
| Brake Disc Type | Vented |
| Brake Disc Thickness | 22mm |
| Surface | Coated |
| Fitting Position | Front Axle |
| Num. of holes | 4 |
| Outer Diameter | 258mm |
| Outer Diameter | 257mm |
| Brake Disc Thickness | 22mm |
| Min. thickness | 20.2mm |
| Height | 41mm |
| Rim | 4-Hole |
| Brake Disc Type | Vented |
| Centering Diameter | 59mm |
| Bolt Hole Circle Ø | 98mm |
| Hub Ø | 137mm |
| More information » | |
| Rim | 6-Hole |
| Fitting Position | Front Axle |
| Length | 257.2mm |
| Height | 40.3mm |
| Brake Disc Type | Vented |
| Brake Disc Thickness | 22mm |
| Min. thickness | 20.2mm |
| Outer Diameter | 258mm |
| Centering Diameter | 59mm |
| Surface | Oiled |
| More information » | |
| Brake System | ATE |
| Num. of holes | 4 |
| Height | 40.5mm |
| Brake Disc Type | vented |
| Brake Disc Thickness | 22mm |
| Centering Diameter | 59mm |
| Min. thickness | 20.2mm |
| Outer Diameter | 257mm |
| More information » | |
| Height | 40.5mm |
| Brake Disc Thickness | 22mm |
| Outer Diameter | 257mm |
| Num. of holes | 4 |
| Centering Diameter | 59mm |
| Brake Disc Type | vented |
| usable for vehicles to construction year | 11.2016 |
| Fitting Position | Front Axle |
| Height | 40.3mm |
| Brake Disc Type | Vented |
| Brake Disc Thickness | 22mm |
| Material | Cast Iron |
| Processing | Untreated |
| Outer Diameter | 257.2mm |
| Centering Diameter | 59mm |
| Bolt Hole Circle Ø | 98mm |
| Surface | Uncoated |
| Supplementary Article/Supplementary Info 2 | without bolts/screws |
| Wheel Bolt Bore Ø | 13mm |
| More information » | |
| usable for vehicles to construction year | 11.2016 |
| Fitting Position | Front Axle |
| Height | 40.3mm |
| Brake Disc Type | Vented |
| Brake Disc Thickness | 22mm |
| Material | Cast Iron |
| Processing | Untreated |
| Outer Diameter | 257.2mm |
| Centering Diameter | 59mm |
| Bolt Hole Circle Ø | 98mm |
| Surface | Uncoated |
| Supplementary Article/Supplementary Info 2 | without bolts/screws |
| Wheel Bolt Bore Ø | 13mm |
| More information » | |
| Fitting Position | Front Axle |
| Height | 40.4mm |
| Brake Disc Type | Vented |
| Brake Disc Thickness | 22mm |
| Outer Diameter | 257mm |
| Num. of holes | 4 |
| Centering Diameter | 59mm |
| Bolt Hole Circle Ø | 98mm |
| More information » | |
| Brake Disc Thickness | 22mm |
| Rim | 4-Hole |
| Thickness | 40.5mm |
| Outer Diameter | 257mm |
| Bolt Hole Circle Ø | 98mm |
| Surface | Coated |
| Brake Disc Type | vented |
| Fitting Position | Front Axle |
| Min. thickness | 20.5mm |
| Centering Diameter | 59mm |
| Guarantee | 3 years guarantee |
| More information » | |
| Brake Disc Type | Vented |
| Num. of holes | 4 |
| Appr. stamp | R90 Homologated |
| Surface | Oiled |
| Outer Diameter | 257mm |
| Brake Disc Thickness | 22mm |
| Min. thickness | 20.2mm |
| Bolt Hole Circle Ø | 98mm |
| Centering Diameter | 59mm |
| Height | 40.3mm |
| More information » | |
| Brake Disc Thickness | 22mm |
| Rim | 4-Hole |
| Thickness | 40.5mm |
| Outer Diameter | 257mm |
| Bolt Hole Circle Ø | 98mm |
| Surface | Coated |
| Brake Disc Type | vented |
| Fitting Position | Front Axle |
| Min. thickness | 20.5mm |
| Centering Diameter | 59mm |
| Observe service information | |
| Guarantee | 3 years guarantee |
| More information » | |
$21.90
$25.70
-15%
Sold in pairs
| Num. of holes | 4 |
| Height | 40.5mm |
| Brake System | ATE |
| Surface | Coated |
| Centering Diameter | 59mm |
| Min. thickness | 20.2mm |
| Brake Disc Thickness | 22mm |
| Brake Disc Type | vented |
| Outer Diameter | 257mm |
| More information » | |
| Brake Disc Type | vented |
| Outer Diameter | 257mm |
| Brake Disc Thickness | 22mm |
| Supplementary Article/Supplementary Info 2 | without wheel hub, without wheel studs |
| Height | 40.3mm |
| Bolt Hole Circle Ø | 98mm |
| Centering Diameter | 59mm |
| Num. of holes | 4 |
| Surface | painted |
| Min. thickness | 20.2mm |
| More information » | |
| Brake Disc Thickness | 22mm |
| Rim | 4-Hole |
| Thickness | 41mm |
| Outer Diameter | 257mm |
| Bolt Hole Circle Ø | 98mm |
| Surface | Coated |
| Brake Disc Type | vented |
| Fitting Position | Front Axle |
| Min. thickness | 20.5mm |
| Centering Diameter | 59mm |
| Observe service information | |
| Guarantee | 3 years guarantee |
| More information » | |
$24.10
$28.40
-16%
Sold in pairs
| Brake Disc Type | Vented |
| Surface | Galvanically coated |
| Fitting Position | Front Axle |
| Outer Diameter | 257mm |
| Inner Diameter | 127mm |
| Centering Diameter | 59mm |
| Height | 40.7mm |
| Brake Disc Thickness | 22mm |
| Min. thickness | 20.2mm |
| Num. of holes | 4 |
| Thread Size | 13, 2 |
| Weight | 5.1kg |
| Bolt Hole Circle Ø | 98mm |
| More information » | |
| Brake Disc Type | Vented |
| Outer Diameter | 257mm |
| Brake Disc Thickness | 22mm |
| Min. thickness | 20.2mm |
| Centering Diameter | 59mm |
| Height | 40.4mm |
| Num. of holes | 4 |
| Thread Size | 13 |
| Bolt Hole Circle Ø | 98mm |
| Colour | black |
| Surface | painted |
| Appr. stamp | E190R-02C0176/0520 |
| SVHC | No information available, please contact the manufacturer! |
| More information » | |
| Fitting Position | Front Axle |
| Brake Disc Type | Vented |
| Brake Disc Thickness | 22mm |
| Outer Diameter | 257mm |
| Weight | 5.229kg |
| Height | 40.6mm |
| Num. of holes | 4 |
| Bolt Hole Circle Ø | 98mm |
| Centering Diameter | 59mm |
| Surface | Coated |
| Min. thickness | 20.2mm |
| Drill Ø, up to | 13mm |
| More information » | |
$24.80
$29.20
-16%
Sold in pairs
| Brake Disc Type | Vented |
| Outer Diameter | 257mm |
| Brake Disc Thickness | 22mm |
| Height | 40.5mm |
| Centering Diameter | 59mm |
| Number of mounting bores | 4 |
| Surface | Coated |
| Weight | 5.35kg |
| Min. thickness | 20mm |
| More information » | |
| Brake Disc Type | vented |
| Outer Diameter | 257mm |
| Brake Disc Thickness | 22mm |
| Height | 40.3mm |
| Bolt Hole Circle Ø | 98mm |
| Centering Diameter | 59mm |
| Num. of holes | 4 |
| Surface | Coated |
| Min. thickness | 20.2mm |
| Number of bores | 2 |
| More information » | |
| Fitting Position | Front Axle |
| Outer Diameter | 257.5mm |
| Height | 40.5mm |
| Brake Disc Thickness | 22mm |
| Min. thickness | 20.2mm |
| Centering Diameter | 59mm |
| Bolt Hole Circle Ø | 98mm |
| Wheel Bolt Bore Ø | 13mm |
| Num. of holes | 4 |
| Brake Disc Type | Vented |
| Quantity required | 2 |
| More information » | |
| Outer Diameter | 257.2mm |
| Brake Disc Thickness | 22mm |
| Min. thickness | 20.2mm |
| Height | 40.5mm |
| Bolt Hole Circle Ø | 98mm |
| Brake Disc Type | Vented |
| Centering Diameter | 59mm |
| Num. of holes | 4 |
| Surface | Coated |
| fulfils ECE standard | ECE-R90 |
| Drill Ø, up to | 13mm |
| More information » | |
| Thickness | 22mm |
| Height | 39.4mm |
| Brake Disc Type | Vented |
| Brake Disc Thickness | 22mm |
| Min. thickness | 20.2mm |
| Num. of holes | 4 |
| Centering Diameter | 59mm |
| Wear Warning Contact | incl. wear warning contact, with integrated wear warning contact |
| Supplementary Article/Supplementary Info 2 | with bolts/screws |
| Fitting Position | Front Axle |
| Outer Diameter | 284mm |
| Surface | Coated |
| Tightening Torque | 86Nm |
| Bolt Hole Circle Ø | 98mm |
| More information » | |
