AUDI: 4B0.615.601B
AUDI: 4B0615601B
AUDI: 4B0 615 601B
AUDI: 4B0 615 601 B
SEAT: 4B0615601B
SEAT: 4B0 615 601 B
SKODA: 4B0615601B
SKODA: 4B0 615 601 B
SKODA: 4B0 615 601B
VAG: 4B0 615 601B
VAG: 4B0 615 601 B
VAG: 4B0615601B
VW: 4B0615601B
VW: 4B0 615 601B
VW: 4B0 615 601 B
OE number or original number means the number of the whole component or part of it installed on the vehicle on the production line by the car manufacturer. The meaning of the OE number is equivalent to "Genuine Number"
Previous
1 2 Next
cheapest first
expensive first
popular products first
by name
by newest
Fitting Position Rear Axle
Brake Disc Type solid
Outer Diameter 255mm
Brake Disc Thickness 10mm
Height 47.6mm
Min. thickness 8mm
Centering Diameter 68mm
Bolt Hole Circle Ø 112mm
Surface Oiled
More information »
Rim 5-Hole
Height 47.5mm
Brake Disc Type solid
Brake Disc Thickness 9.9mm
Min. thickness 8mm
Outer Diameter 255mm
Surface Coated
Hub Ø 68mm
More information »
2 pictures
Fitting Position Rear Axle
Brake Disc Type solid
Outer Diameter 255mm
Brake Disc Thickness 10mm
Height 48mm
Bolt Hole Circle Ø 112mm
Centering Diameter 68mm
Num. of holes 5
Min. thickness 8mm
More information »
3 pictures
Fitting Position Rear Axle
Rim 5-Hole
Height 48.1mm
Brake Disc Type solid
Brake Disc Thickness 10mm
Min. thickness 8mm
Outer Diameter 255mm
Centering Diameter 68mm
Bolt Hole Circle Ø 112mm
Brake Disc Hub Height 38mm
More information »
3 pictures
Outer Diameter 255mm
Brake Disc Thickness 10mm
Min. thickness 8mm
Height 47.5mm
Rim 5-Hole
Brake Disc Type solid
Centering Diameter 68mm
Bolt Hole Circle Ø 112mm
Surface Coated
Hub Ø 146mm
More information »
Brake Disc Type solid
Outer Diameter 255mm
Brake Disc Thickness 10mm
Min. thickness 8mm
Inner Diameter 144.5mm
Bore Ø 15.3mm
Bolt Hole Circle Ø 112mm
Num. of holes 5
Height 48.1mm
Centering Diameter 68mm
EU General Product Safety Regulation (GPSR) IEC 60417-6183 mechanical expertise required
More information »
2 pictures
Brake Disc Type solid
Brake Disc Thickness 10mm
Surface Coated
Fitting Position Rear Axle
Num. of holes 5
Outer Diameter 255mm
Fitting Position Rear Axle
Height 47.6mm
Brake Disc Type solid
Brake Disc Thickness 10mm
Material Cast Iron
Processing Untreated
Num. of holes 5
Centering Diameter 68mm
Bolt Hole Circle Ø 112mm
Surface Uncoated
Supplementary Article/Supplementary Info 2 without bolts/screws
Wheel Bolt Bore Ø 15.7mm
Outer Diameter 255mm
More information »
2 pictures
Brake Disc Type solid
Outer Diameter 255mm
Brake Disc Thickness 10mm
Supplementary Article/Supplementary Info 2 without wheel hub, without wheel studs
Height 47.6mm
Bolt Hole Circle Ø 112mm
Centering Diameter 68mm
Num. of holes 5
Surface painted
Min. thickness 8mm
More information »
2 pictures
Fitting Position Rear Axle
Brake Disc Type solid
Brake Disc Thickness 10mm
Bolt Hole Circle Ø 112mm
Num. of holes 5
Rim 5-Hole
Height 48mm
Centering Diameter 68mm
Surface Coated
Outer Diameter 255mm
More information »
Brake Disc Type solid
Num. of holes 5
Appr. stamp R90 Homologated
Surface Oiled
Outer Diameter 255mm
Brake Disc Thickness 9.9mm
Bolt Hole Circle Ø 112mm
Centering Diameter 68mm
Height 48mm
More information »
Appr. stamp ECE-R90
Height 47.8mm
Brake Disc Type solid
Brake Disc Thickness 10mm
Outer Diameter 255mm
Num. of holes 5
Centering Diameter 68mm
Surface painted
More information »
3 pictures
Brake Disc Thickness 10mm
Rim 5-Hole
Thickness 48mm
Outer Diameter 255mm
Bolt Hole Circle Ø 112mm
Surface Coated
Brake Disc Type solid
Fitting Position Rear Axle
Min. thickness 8mm
Centering Diameter 68mm
Observe service information Guarantee 3 years guarantee
More information »
Brake Disc Type solid
Brake Disc Thickness 10mm
Height 48mm
Outer Diameter 255mm
Centering Diameter 68mm
Min. thickness 8mm
Num. of holes 5
More information »
3 pictures
Brake Disc Thickness 10mm
Rim 5-Hole
Thickness 48mm
Outer Diameter 255mm
Bolt Hole Circle Ø 112mm
Surface Coated
Brake Disc Type solid
Fitting Position Rear Axle
Min. thickness 8mm
Centering Diameter 68mm
Observe service information Guarantee 3 years guarantee
More information »
2 pictures
Brake Disc Thickness 10mm
Min. thickness 8mm
Brake Disc Type solid
Num. of holes 5
Surface Coated
Height 48.1mm
Centering Diameter 68mm
Inner Diameter 144.5mm
Bolt Hole Circle Ø 112mm
Bore Ø 15.3mm
Fitting Position Rear Axle
Outer Diameter 255mm
More information »
3 pictures
Outer Diameter 255mm
Brake Disc Thickness 10mm
Min. thickness 8mm
Height 47.6mm
Rim 5-Hole
Brake Disc Type solid
Centering Diameter 68mm
Surface Coated
Net weight 3.6kg
New Part More information »
2 pictures
Brake Disc Type solid
Outer Diameter 255mm
Brake Disc Thickness 10mm
Height 48mm
Centering Diameter 68mm
Number of mounting bores 5
Surface Coated
Weight 3.63kg
Min. thickness 8mm
More information »
Fitting Position Rear Axle
Outer Diameter 255mm
Height 48.1mm
Brake Disc Thickness 10mm
Min. thickness 8mm
Centering Diameter 68mm
Bolt Hole Circle Ø 112mm
Wheel Bolt Bore Ø 15.3mm
Num. of holes 5
Brake Disc Type solid
Quantity required 2
More information »
5 pictures
Brake Disc Type solid
Outer Diameter 255mm
Brake Disc Thickness 10mm
Min. thickness 8mm
Centering Diameter 68mm
Height 48mm
Num. of holes 5
Thread Size 15, 5
Bolt Hole Circle Ø 112mm
Colour black
Surface painted
Appr. stamp E1 90R-02 C0190/0016
SVHC No information available, please contact the manufacturer!
More information »
2 pictures
Brake Disc Thickness 10mm
Fitting Position Rear Axle
Min. thickness 8mm
Brake Disc Type solid
Num. of holes 5
Surface Coated
Height 48.1mm
Centering Diameter 68mm
Inner Diameter 144.5mm
Bolt Hole Circle Ø 112mm
Bore Ø 15.3mm
Outer Diameter 255mm
Processing High-carbon
More information »
Fitting Position Rear Axle
Brake Disc Type solid
Brake Disc Thickness 10mm
Min. thickness 8mm
Outer Diameter 255mm
Bolt Hole Circle Ø 112mm
Num. of holes 5
More information »
6 pictures
Outer Diameter 254.7mm
Brake Disc Thickness 10mm
Min. thickness 8mm
Height 47.6mm
Bolt Hole Circle Ø 112mm
Brake Disc Type solid
Centering Diameter 68mm
Num. of holes 5
Surface Coated
Processing High-carbon
fulfils ECE standard ECE-R90
Drill Ø, up to 15.7mm
More information »
Partnumber: 0 986 478 480
Sold in pairs
Fitting Position Rear Axle
Brake Disc Type solid
Surface Coated
Outer Diameter 255mm
Brake Disc Thickness 10mm
Height 48mm
Rim 5-Hole
Bolt Hole Circle Ø 112mm
Centering Diameter 68mm
Appr. stamp ECE R90 APPROVED
Min. thickness 8mm
Hole Pitch/Number 5/5
Weight 3.5kg
More information »
2 pictures
Brake Disc Type solid
Brake Disc Thickness 10mm
Num. of holes 5
Height 48mm
Centering Diameter 68mm
Outer Diameter 255mm
Surface Coated
Min. thickness 8mm
Tightening Torque 120Nm
More information »
2 pictures
Brake Disc Type solid
Outer Diameter 255mm
Brake Disc Thickness 10mm
Brake System TRW
Quantity required 1
Supplementary Article/Supplementary Info 2 without bolts/screws
Version JC
Height 47.8mm
Bolt Hole Circle Ø 112mm
Centering Diameter 68mm
Num. of holes 5
Quantity Unit Set
Surface Coated
Weight 7.23kg
Min. thickness 8mm
Tightening Torque 120Nm
Container Type Carton
Packaging length 27.5cm
Packaging width 27.5cm
Packaging height 11cm
More information »
Brake Disc Type solid
Outer Diameter 255mm
Brake Disc Thickness 10mm
Height 47.6mm
Min. thickness 8mm
Surface Coated
Inner Diameter 143.5mm
Bolt Hole Circle Ø 112mm
Centering Diameter 68mm
Hole Pitch/Number 05/05
Wheel Bolt Bore Ø 15.7mm
Supplementary Article/Supplementary Info 2 without wheel hub, without wheel bearing, without wheel studs
Packaging length 27.8cm
Packaging width 27.8cm
Packaging height 12.2cm
Weight 3.6kg
More information »
4 pictures
Brake Disc Type solid
Outer Diameter 255mm
Brake Disc Thickness 10mm
Height 47.6mm
Min. thickness 8mm
Surface Coated
Bolt Hole Circle Ø 112mm
Centering Diameter 68mm
Hole Pitch/Number 05/05
Supplementary Article/Supplementary Info 2 without wheel hub, without wheel studs
Weight 3.5kg
Assy./disassy. by qualified personnel required! More information »
Partnumber: 8DD 355 109-091
Sold in pairs
Brake Disc Type solid
Outer Diameter 255mm
Brake Disc Thickness 10mm
Height 47.6mm
Min. thickness 8mm
Surface Coated
Inner Diameter 143.5mm
Bolt Hole Circle Ø 112mm
Centering Diameter 68mm
Hole Pitch/Number 05/05
Wheel Bolt Bore Ø 15.7mm
Supplementary Article/Supplementary Info 2 without wheel hub, without wheel bearing, without wheel studs
Packaging length 27.8cm
Packaging width 27.8cm
Packaging height 8.4cm
Weight 3.6kg
More information »
2 pictures
Outer Diameter 255mm
Brake Disc Thickness 10mm
Min. thickness 8mm
Brake Disc Type solid
Num. of holes 5
Surface Coated
Height 48.1mm
Centering Diameter 68mm
Inner Diameter 144.5mm
Bolt Hole Circle Ø 112mm
Bore Ø 15.3mm
MAPP code available Appr. stamp E1 90R-02C0165/0854
More information »
Partnumber: 24.0110-0260.1
Sold in pairs
