AUDI: 4F0615601E
AUDI: 4F0 615 601E
AUDI: 4F0 615 601 E
AUDI (FAW): 4F0615601E
AUDI (FAW): 4F0 615 601 E
SEAT: 4F0615601E
SEAT: 4F0 615 601 E
SKODA: 4F0615601E
SKODA: 4F0 615 601 E
VAG: 4F0 615 601E
VAG: 4F0 615 601 E
VAG: 4F0615601E
VW: 4F0615601E
VW: 4F0 615 601 E
OE number or original number means the number of the whole component or part of it installed on the vehicle on the production line by the car manufacturer. The meaning of the OE number is equivalent to "Genuine Number"
Previous
1 2 Next
cheapest first
expensive first
popular products first
by name
by newest
Fitting Position Rear Axle
Brake Disc Type solid
Outer Diameter 302mm
Brake Disc Thickness 12mm
Height 49.2mm
Min. thickness 10mm
Centering Diameter 68mm
Bolt Hole Circle Ø 112mm
Surface Oiled
More information »
Rim 5-Hole
Height 49mm
Brake Disc Type solid
Brake Disc Thickness 12mm
Min. thickness 10mm
Outer Diameter 302mm
Surface Coated
Hub Ø 68mm
Wheel Bolt Bore Ø 112mm
More information »
4 pictures
Fitting Position Rear Axle
Brake Disc Type solid
Brake Disc Thickness 12mm
Outer Diameter 302mm
Surface Oiled
Height 49.2mm
Min. thickness 10mm
Centering Diameter 68mm
Num. of holes 9
Bolt Hole Circle Ø 112mm
Thread Size 15.5
More information »
4 pictures
Fitting Position Rear Axle
Brake Disc Type solid
Brake Disc Thickness 12mm
Outer Diameter 302mm
Surface Coated
Height 49.2mm
Min. thickness 10mm
Centering Diameter 68mm
Num. of holes 9
Bolt Hole Circle Ø 112mm
Supplementary Article/Supplementary Info 2 with screw
Thread Size 15.5
More information »
4 pictures
Brake Disc Type solid
Brake Disc Thickness 12mm
Outer Diameter 302mm
Bolt Hole Circle Ø 112mm
Height 49.2mm
Brake Disc Thickness 12mm
Outer Diameter 302mm
Num. of holes 5
Centering Diameter 68mm
Brake Disc Type solid
3 pictures
Brake Disc Type solid
Outer Diameter 302mm
Brake Disc Thickness 12mm
Quantity required 2
Replace in pairs only Height 49.4mm
Bolt Hole Circle Ø 112mm
Centering Diameter 68mm
Num. of holes 5
Appr. stamp ECE R90
Assy./disassy. by qualified personnel required! More information »
2 pictures
Fitting Position Rear Axle
Brake Disc Type solid
Outer Diameter 302mm
Brake Disc Thickness 12mm
Height 49.2mm
Bolt Hole Circle Ø 112mm
Centering Diameter 68mm
Num. of holes 9
Min. thickness 10mm
More information »
Brake Disc Thickness 12mm
Centering Diameter 68mm
Num. of holes 5
Brake System BENDIX - BOSCH
Min. thickness 10mm
Brake Disc Type solid
Height 49.2mm
Outer Diameter 302mm
More information »
2 pictures
Outer Diameter 302mm
Height 49.2mm
Brake Disc Type solid
Brake Disc Thickness 12mm
Min. thickness 10mm
Num. of holes 5
Surface painted
Fitting Position Rear Axle
Tightening Torque 120Nm
for OE No. 4F0615601E
More information »
3 pictures
Outer Diameter 302mm
Brake Disc Thickness 12mm
Min. thickness 10mm
Height 49.1mm
Rim 5-Hole
Brake Disc Type solid
Centering Diameter 68mm
Bolt Hole Circle Ø 112mm
Surface Coated
Hub Ø 150mm
More information »
2 pictures
Brake Disc Thickness 12mm
Min. thickness 10mm
Brake Disc Type solid
Surface Coated
Bolt Hole Circle Ø 112mm
Height 49.4mm
Centering Diameter 68mm
Inner Diameter 177mm
Bore Ø 15.3mm
Num. of holes 9
Fitting Position Rear Axle
Outer Diameter 302mm
More information »
Brake Disc Type solid
Outer Diameter 302mm
Brake Disc Thickness 12mm
Min. thickness 10mm
Inner Diameter 177mm
Bore Ø 15.3mm
Bolt Hole Circle Ø 112mm
No. of holes 2 9
Num. of holes 5
Height 49.4mm
Centering Diameter 68mm
EU General Product Safety Regulation (GPSR) IEC 60417-6183 mechanical expertise required
More information »
2 pictures
Brake Disc Type solid
Brake Disc Thickness 12mm
Surface Coated
Fitting Position Rear Axle
Num. of holes 5
Outer Diameter 302mm
3 pictures
Rim 5-Hole
Fitting Position Rear Axle
Length 301.7mm
Height 49.2mm
Brake Disc Type solid
Brake Disc Thickness 12mm
Min. thickness 10mm
Outer Diameter 302mm
Centering Diameter 68mm
Surface Oiled
No. of holes 1 1
Number of mounting bores 4
More information »
Partnumber: DP1010.11.0242
Sold in pairs
Fitting Position Rear Axle
Height 49.2mm
Brake Disc Type solid
Brake Disc Thickness 12mm
Material Cast Iron
Processing Untreated
Outer Diameter 301.7mm
Centering Diameter 68mm
Bolt Hole Circle Ø 112mm
Surface Uncoated
Supplementary Article/Supplementary Info 2 without bolts/screws
Wheel Bolt Bore Ø 15.3mm
More information »
Appr. stamp ECE-R90
Height 49mm
Brake Disc Type solid
Brake Disc Thickness 12mm
Outer Diameter 302mm
Num. of holes 5
Centering Diameter 68mm
Surface painted
More information »
Fitting Position Rear Axle
Height 49.2mm
Brake Disc Type solid
Brake Disc Thickness 12mm
Material Cast Iron
Processing Untreated
Outer Diameter 301.7mm
Centering Diameter 68mm
Bolt Hole Circle Ø 112mm
Surface Uncoated
Supplementary Article/Supplementary Info 2 without bolts/screws
Wheel Bolt Bore Ø 15.3mm
More information »
Brake Disc Thickness 12mm
Rim 5-Hole
Number of mounting bores 1
Thickness 49mm
Outer Diameter 302mm
Bolt Hole Circle Ø 112mm
Surface Coated
Brake Disc Type solid
Fitting Position Rear Axle
Min. thickness 10mm
Centering Diameter 68mm
Observe service information Guarantee 3 years guarantee
More information »
Brake Disc Type solid
Outer Diameter 302mm
Brake Disc Thickness 12mm
Supplementary Article/Supplementary Info 2 without wheel hub, without wheel studs
Height 49.2mm
Bolt Hole Circle Ø 112mm
Centering Diameter 68mm
Num. of holes 5
Surface painted
Min. thickness 10mm
More information »
4 pictures
Brake Disc Type solid
Outer Diameter 302mm
Brake Disc Thickness 12mm
Height 49.2mm
Min. thickness 10mm
Surface Coated
Inner Diameter 176.9mm
Bolt Hole Circle Ø 112mm
Centering Diameter 68mm
Hole Pitch/Number 05/10
Wheel Bolt Bore Ø 15.3mm
Supplementary Article/Supplementary Info 2 without wheel hub, without wheel bearing, without wheel studs
Weight 5.4kg
Assy./disassy. by qualified personnel required! More information »
Partnumber: 8DD 355 111-181
Sold in pairs
2 pictures
Brake Disc Type solid
Surface Galvanically coated
Fitting Position Rear Axle
Outer Diameter 301.7mm
Inner Diameter 138mm
Centering Diameter 68mm
Height 49.2mm
Brake Disc Thickness 12mm
Min. thickness 10mm
Num. of holes 9
Thread Size 15, 3
No. of holes 1 1
Bore Distance 1 112mm
Weight 5.3kg
Bolt Hole Circle Ø 112mm
More information »
4 pictures
Fitting Position Rear Axle
Brake Disc Type solid
Surface Coated
Outer Diameter 302mm
Brake Disc Thickness 12mm
Centering Diameter 68mm
Height 49.2mm
Min. thickness 10mm
Rim 9-Hole
Number of mounting bores 1
Supplementary Article/Supplementary Info 2 without bolts/screws, without ABS sensor ring, without integrated wheel bearing
Weight 11.18kg
More information »
Brake Disc Thickness 12mm
Rim 5-Hole
Number of mounting bores 1
Thickness 49.2mm
Outer Diameter 302mm
Bolt Hole Circle Ø 112mm
Surface Coated
Brake Disc Type solid
Fitting Position Rear Axle
Min. thickness 10mm
Centering Diameter 68mm
Observe service information Guarantee 3 years guarantee
More information »
Brake Disc Type solid
Num. of holes 5
Appr. stamp R90 Homologated
Outer Diameter 302mm
Brake Disc Thickness 12mm
Bolt Hole Circle Ø 112mm
Centering Diameter 68mm
Height 49.2mm
More information »
3 pictures
Outer Diameter 302mm
Brake Disc Thickness 12mm
Min. thickness 10mm
Height 49.2mm
Rim 5-Hole
Brake Disc Type solid
Centering Diameter 68mm
Surface Coated
Net weight 5.32kg
New Part More information »
Fitting Position Rear Axle
Outer Diameter 302mm
Height 49mm
Brake Disc Thickness 12mm
Min. thickness 10mm
Centering Diameter 68mm
Bolt Hole Circle Ø 112mm
Wheel Bolt Bore Ø 15.3mm
Num. of holes 5
Brake Disc Type solid
Quantity required 2
More information »
Fitting Position Rear Axle
Brake Disc Type solid
Brake Disc Thickness 12mm
Outer Diameter 302mm
Weight 5.24kg
Height 49.2mm
Num. of holes 9
Bolt Hole Circle Ø 112mm
Centering Diameter 68mm
Surface Coated
Min. thickness 10mm
Drill Ø, up to 15.4mm
More information »
Brake Disc Thickness 12mm
Rim 5-Hole
Number of mounting bores 1
Thickness 49.2mm
Outer Diameter 302mm
Bolt Hole Circle Ø 112mm
Surface Coated
Brake Disc Type solid
Fitting Position Rear Axle
Min. thickness 10mm
Centering Diameter 68mm
Guarantee 3 years guarantee
More information »
Brake Disc Type solid
Outer Diameter 302mm
Brake Disc Thickness 12mm
Height 49.2mm
Bolt Hole Circle Ø 112mm
Centering Diameter 68mm
Num. of holes 9
Surface Coated
Min. thickness 10mm
Number of bores 1
More information »
