CHEVROLET: 569042
DAEWOO: 569042
DAEWOO: 5 69 042
GENERAL MOTORS: 569042
GENERAL MOTORS: 5 69 042
HOLDEN: 569042
OPEL: 569042
OPEL: 5 69 042
OPEL: 569 042
PONTIAC: 569042
VAUXHALL: 569042
VAUXHALL: 5 69 042
OE number or original number means the number of the whole component or part of it installed on the vehicle on the production line by the car manufacturer. The meaning of the OE number is equivalent to "Genuine Number"
cheapest first
expensive first
popular products first
by name
by newest
Fitting Position Front Axle
Brake Disc Type Vented
Outer Diameter 256mm
Brake Disc Thickness 24mm
Height 41mm
Num. of holes 6
Min. thickness 21mm
Centering Diameter 60mm
Bolt Hole Circle Ø 100mm
Surface Oiled
More information »
Fitting Position Front Axle
Height 41mm
Brake Disc Type Vented
Brake Disc Thickness 20mm
Material Cast Iron
Processing Untreated
Outer Diameter 236mm
Centering Diameter 60mm
Bolt Hole Circle Ø 100mm
Surface Uncoated
Supplementary Article/Supplementary Info 2 without bolts/screws
Wheel Bolt Bore Ø 14.4mm
More information »
Fitting Position Front Axle
Brake Disc Type solid
Surface Coated
Processing High-carbon
Outer Diameter 237mm
Brake Disc Thickness 11mm
Height 55.5mm
Min. thickness 10mm
Rim 4-Hole
Supplementary Article/Supplementary Info 2 without bolts/screws, without ABS sensor ring, without integrated wheel bearing
Appr. stamp ECE-R90
Weight 3.75kg
More information »
Fitting Position Front Axle
Brake Disc Type Vented
Outer Diameter 256mm
Brake Disc Thickness 24mm
Supplementary Article/Supplementary Info 2 with bolts/screws
Height 41mm
Bolt Hole Circle Ø 100mm
Centering Diameter 60mm
Num. of holes 6
Min. thickness 21mm
More information »
Fitting Position Front Axle
Brake Disc Type Vented
Outer Diameter 256mm
Hub Ø 133mm
Centering Diameter 60mm
Brake Disc Thickness 24mm
Height 41mm
Rim 4-Hole
Bolt Hole Circle Ø 100mm
Replace in pairs only More information »
Height 41mm
Brake Disc Type vented
Centering Diameter 60mm
Min. thickness 21mm
Outer Diameter 256mm
Num. of holes 4
Brake Disc Thickness 24mm
More information »
Brake Disc Type Vented
Outer Diameter 256mm
Brake Disc Thickness 24mm
Min. thickness 21mm
Inner Diameter 123mm
Bore Ø 14mm
Bolt Hole Circle Ø 100mm
No. of holes 2 6
Num. of holes 4
Height 41mm
Centering Diameter 60mm
EU General Product Safety Regulation (GPSR) IEC 60417-6183 mechanical expertise required
More information »
3 pictures
Outer Diameter 256mm
Brake Disc Thickness 24mm
Min. thickness 21mm
Height 41mm
Rim 4-Hole
Brake Disc Type Vented
Centering Diameter 60mm
Bolt Hole Circle Ø 100mm
Surface Coated
Hub Ø 134mm
More information »
Brake Disc Type Externally Vented
Outer Diameter 256mm
Brake Disc Thickness 24mm
Supplementary Article/Supplementary Info 2 without wheel hub, without wheel studs
Height 41mm
Bolt Hole Circle Ø 100mm
Centering Diameter 60mm
Num. of holes 4
Surface painted
Min. thickness 21mm
More information »
2 pictures
Appr. stamp ECE-R90
Height 41mm
Brake Disc Type Vented
Brake Disc Thickness 24mm
Outer Diameter 256mm
Num. of holes 4
Centering Diameter 60mm
More information »
7 pictures
Fitting Position Front Axle
Height 41mm
Brake Disc Type Vented
Brake Disc Thickness 24mm
Material Cast Iron
Processing Untreated
Outer Diameter 256mm
Centering Diameter 60mm
Bolt Hole Circle Ø 100mm
Surface Uncoated
Supplementary Article/Supplementary Info 2 without bolts/screws
Wheel Bolt Bore Ø 14mm
More information »
Brake Disc Type Vented
Num. of holes 4
Appr. stamp R90 Homologated
Surface Oiled
Outer Diameter 256mm
Brake Disc Thickness 24mm
Min. thickness 21mm
Bolt Hole Circle Ø 100mm
Centering Diameter 60mm
Height 41mm
More information »
3 pictures
Brake Disc Thickness 24mm
Rim 4-Hole
Number of mounting bores 1
Thickness 41mm
Outer Diameter 256mm
Bolt Hole Circle Ø 100mm
Surface Coated
Brake Disc Type vented
Fitting Position Front Axle
Min. thickness 21mm
Centering Diameter 60mm
Observe service information Guarantee 3 years guarantee
More information »
Brake Disc Type vented
Outer Diameter 256mm
Brake Disc Thickness 24mm
Height 41mm
Bolt Hole Circle Ø 100mm
Centering Diameter 60mm
Num. of holes 6
Min. thickness 21mm
Number of bores 1
More information »
5 pictures
Surface painted
Brake Disc Type Vented
Outer Diameter 256mm
Brake Disc Thickness 24mm
Min. thickness 21mm
Centering Diameter 60mm
Height 41mm
Num. of holes 6
Thread Size 14
Bolt Hole Circle Ø 100mm
Colour black
Supplementary Article/Supplementary Info 2 with bolts/screws
SVHC No information available, please contact the manufacturer!
More information »
2 pictures
Fitting Position Front Axle
Bolt Hole Circle Ø 60mm
Height 41.2mm
Outer Diameter 255.8mm
Brake Disc Thickness 23.8mm
Min. thickness 22mm
Number of bores 4
Brake Disc Type Vented
Appr. stamp ECE R90 APPROVED
Surface painted
Tightening Torque 110Nm
for OE No. 5561178J02
More information »
Fitting Position Front Axle
Outer Diameter 256mm
Height 41mm
Brake Disc Thickness 24mm
Min. thickness 21mm
Centering Diameter 60mm
Bolt Hole Circle Ø 100mm
Wheel Bolt Bore Ø 14mm
Num. of holes 4
Brake Disc Type Vented
Quantity required 2
More information »
2 pictures
Brake Disc Type vented
Brake Disc Thickness 24mm
Num. of holes 4
Supplementary Article/Supplementary Info 2 with bolts/screws
Height 41mm
Centering Diameter 60mm
Outer Diameter 256mm
Min. thickness 21mm
Tightening Torque 110Nm
More information »
2 pictures
Thickness 24mm
Height 41mm
Brake Disc Type Vented
Brake Disc Thickness 24mm
Min. thickness 21mm
Num. of holes 6
Centering Diameter 60mm
Wear Warning Contact incl. wear warning contact, with integrated wear warning contact
Supplementary Article/Supplementary Info 2 with bolts/screws
Fitting Position Front Axle
Outer Diameter 256mm
More information »
6 pictures
Outer Diameter 255.9mm
Brake Disc Thickness 23.9mm
Min. thickness 21mm
Height 41mm
Bolt Hole Circle Ø 100mm
Brake Disc Type Vented
Centering Diameter 60.03mm
Num. of holes 4
Surface Oiled
Processing Alloyed/High-carbon
Supplementary Article/Supplementary Info 2 with bolts/screws
fulfils ECE standard ECE-R90
Drill Ø, up to 14.3mm
More information »
Partnumber: 0 986 478 327
Sold in pairs
Fitting Position Front Axle
Brake Disc Type Externally Vented
Surface Coated
Outer Diameter 256mm
Brake Disc Thickness 24mm
Height 41mm
Rim 4-Hole
Bolt Hole Circle Ø 100mm
Centering Diameter 60mm
Appr. stamp ECE R90 APPROVED
Min. thickness 21mm
Hole Pitch/Number 7/4
Weight 5.2kg
More information »
Brake Disc Type Externally Vented
Outer Diameter 256mm
Brake Disc Thickness 24mm
Height 41mm
Min. thickness 21mm
Surface Coated
Inner Diameter 123mm
Bolt Hole Circle Ø 100mm
Centering Diameter 60mm
Hole Pitch/Number 04/07
Wheel Bolt Bore Ø 14.3mm
Supplementary Article/Supplementary Info 2 without wheel hub, without wheel bearing, without wheel studs
Packaging length 27.8cm
Packaging width 27.8cm
Packaging height 10.5cm
Weight 5.2kg
More information »
Fitting Position Front Axle
Brake Disc Type Vented
Outer Diameter 256mm
Brake Disc Thickness 24mm
Height 41mm
Min. thickness 21mm
Centering Diameter 60mm
Bolt Hole Circle Ø 100mm
Surface painted
More information »
2 pictures
Outer Diameter 256mm
Brake Disc Thickness 24mm
Min. thickness 21mm
Brake Disc Type Vented
Num. of holes 4
Processing Alloyed/High-carbon
Surface Coated
Supplementary Article/Supplementary Info 2 with bolts/screws
MAPP code available No. of holes 2 6
Bolt Hole Circle Ø 100mm
Height 41mm
Centering Diameter 60mm
Inner Diameter 123mm
Bore Ø 14mm
Appr. stamp E1 90R-02C0115/0457
More information »
Partnumber: 24.0124-0115.1
Sold in pairs
2 pictures
Brake Disc Type vented, slotted
Brake Disc Thickness 24mm
Num. of holes 4
Supplementary Article/Supplementary Info 2 with bolts/screws
Height 41mm
Centering Diameter 60mm
Outer Diameter 256mm
Surface Coated
Min. thickness 21mm
Tightening Torque 110Nm
More information »
2 pictures
Outer Diameter 256mm
Brake Disc Thickness 24mm
Min. thickness 21mm
Brake Disc Type Vented
Processing Alloyed/High-carbon
Surface Coated
Num. of holes 4
Bolt Hole Circle Ø 100mm
Height 41mm
Centering Diameter 60mm
Inner Diameter 123mm
Bore Ø 14mm
Supplementary Article/Supplementary Info 2 with bolts/screws
MAPP code available More information »
Partnumber: 24.0324-0115.1
Sold in pairs
3 pictures
Brake Disc Type Vented
Outer Diameter 256mm
Brake Disc Thickness 24mm
Supplementary Article/Supplementary Info 2 with bolts/screws
Height 41mm
Bolt Hole Circle Ø 100mm
Centering Diameter 60mm
Num. of holes 6
Quantity Unit Set
Surface Oiled
Appr. stamp R90 homologated
Weight 10.1kg
Min. thickness 21mm
Tightening Torque 110Nm
Container Type Carton
Packaging length 26cm
Packaging width 26cm
Packaging height 10cm
More information »
Fitting Position Front Axle
Brake Disc Type Externally Vented, Perforated
Surface Coated
Outer Diameter 256mm
Brake Disc Thickness 24mm
Height 41mm
Rim 4-Hole
Bolt Hole Circle Ø 100mm
Centering Diameter 60mm
Appr. stamp ECE R90 APPROVED
Min. thickness 21mm
Hole Pitch/Number 7/4
Weight 5.07kg
More information »
Fitting Position Front Axle
Brake Disc Thickness 24mm
Brake System ATE
Wear Warning Contact excl. wear warning contact
Brake Disc Type Vented
Num. of holes 6
Bolt Hole Circle Ø 100mm
Outer Diameter 256mm
Quantity Unit Set
Multi-piece Multi-piece
More information »
