Multimeter Testboy 313

Technische Daten TESTBOY 313 Overload Category: CAT III 600 V Weight: 380 g incl. batteries Scope of Delivery: 1 × test lead 1 × holster 1 × temperature probe 1 × 9 V battery, 6LR61 Power Supply: 1 × 9 V 6LR61 Diode Test: and Dimensions: 200 × 89 × 38 mm AC Voltage: 2, 20, 200 V, ± 1.0 %, +5 digits 600 V ± 1.2 %, +5 digits AC Current: 2 mA, 20 mA, ± 1.0 %, +5 digits 200 mA ± 1.5 %, +3 digits 10 A ± 2.0 %, +8 digits Operating temperature range: 0 °C to +40 °C (32 °F to 10 4 °F) DC Voltage: 200 mV, 2, 20, 200, ± 0.5 %, +3 digits 600 V ± 0.8 %, +5 digits DC Current: 2 mA, 20 mA, ± 1.0 %, +3 digits 200 mA ± 1.5 %, +3 digits 10 A ± 2.0 %, +5 digits Continuity Test: and Input impedance: > 7.5 MΩ, typ 10 MΩ (AC V & DC V) Frequency Response: 0–20 kHz Capacity: Up to 20 μF Storage temperature range: −10 °C to +50 °C (14 °F to 12 2 °F) Maximum input voltage: 600 V AC/DC Fuses: 200 mA (self-resetting) 10 A/1000 V (flink) Temperature measurement: −20 °C to 1000 °C AC V bandwidth: 50 to 400 Hz Resistance: 200 Ω ± 1.0 %, +5 digits 2 k, 20 k, 200 kΩ ± 1.0 %, +5 digits 2 MΩ, ± 1.0 %, +5 digits 20 MΩ ± 1.5 %, +5 digits
